CPU |
Multimedia SoC (System-on-Chip)
|
Flash |
8 GB
|
RAM |
2 GB
|
Image Sensor |
1/2.8" Progressive CMOS
|
Max. Resolution |
2560×1920 (5MP)
|
Lens Type |
Fixed-focal
|
Focal Length |
f = 2.8 mm
|
Aperture |
F2.0
|
Iris Type |
Fixed iris
|
Field of View |
103.4° (Horizontal)
75.3° (Vertical)
135.2° (Diagonal)
|
Minimum Illumination |
0.055 lux @ F2.0 (Color)
0.005 lux @ F2.0 (B/W)
0 lux with IR illumination on
|
Storage |
Seamless Recording to MicroSD/SDHC/SDXC card (1TB capacity supported) and recording to network-attached storage (NAS)
|
Maximum Frame Rate |
30 fps @ 2560×1920 (5MP)
|
Maximum Streams |
3 video streams (Up to 8 configurable profiles)
|
Main Stream |
30fps @2560×1920,2048×1536,1920×1440,1600×1200,1280×960,800×600,640×480 (4:3)
30fps @ 2560×1440, 1920×1080, 1600×904, 1360×768,1280×720, 640×360 (16:9)
60 fps @ 1920×1080, 1600×904, 1360×768, 1280×720, 640×360 (16:9)
|
Video Streaming |
Adjustable resolution, quality and constant bit rate control, Smart Stream III
|
Image Settings |
General settings
video title and time stamp overlay, video orientation (flip, mirror, rotation), day/night settings
Illuminators
illuminators, anti-overexposure, VCA-based Smart IR III
Image settings
white balance, image adjustment (brightness, contrast, saturation, sharpness, gamma curve), defog, 3DNR, EIS (built-in gyro sensor), scene mode (auto, deblur)
Exposure
BLC, HLC, exposure control (exposure level, iris adjustment, exposure time, gain control, iris mode), AE speed adjustment, WDR
Focus
zoom, focus
Privacy mask
pixel calculator
Scheduled profile settings
|
Audio Capability |
Two-way audio (Full duplex)
|
Compression |
G.711, G.726, MPEG-2 AAC-LC
|
Interface |
Built-in microphone
External microphone Input
External line output
|
Users |
Live viewing for up to 10 clients
|
Security |
Access list, CSRF protection, digest authentication, HTTPS , IEEE 802.1x, Password protection, secure boot, signed firmware, Trend Micro IoT Security (brute force attack event, cyberattack event, quarantine event), user access log, user account management, Built-in FIPS 140-2 Level 2 certified Trusted Platform Module (TPM)
|
Protocols |
802.1X, ARP, Bonjour, CIFS/SMB, DDNS, DHCP, DNS, FTP/SFTP, HTTP, HTTPS, ICMP, IGMPv3, IPv4, IPv6, , NTP, PPPoE, QoS (CoS/DSCP), RTSP/RTP/RTCP, SMTP, SNMP, SSL, TCP/IP, TLS 1.2/1.3, UDP, UPnP
|
Connectors |
RJ-45 cable connector for 10/100 Mbps Network/PoE connection
Audio line input
Audio line output
Digital input: 1
Digital output: 1
|
Operating Temperature |
Starting Temperature:
-20°C ~ 50°C (-4°F ~ 122°F)
Working Temperature:
-35°C ~ 60°C (-31°F ~ 140°F) (IR off)
-35°C ~ 50°C (-31°F ~ 122°F) (IR on)
|
